4 Color Stack Printing Press For Food Packaging Non Woven Bag

Main parameter:

Model	YTB
Type	Stack
Standard Machine width	600mm 800mm 1000mm 1200mm
Material Feeding Width	200-1600mm, also can customized for more width material
Printing Width	160-1560mm, also can customized for more width material
Printing Length	Standard is 400mm，can customized from 300-1000mm
Max Machine Speed	100 m/min
Printing Speed	10-80 m/min Equip chamber doctor blade can reach 100m/min
Register precision	≤0.3mm
Thickness of plate	1.14mm 1.7mm 2.28mm 2.84mm 3.94mm can customized
Gear	1.5mm
Transmission	Synchronous Belt
Heating	Electricity Heating
Double tape thickness for stick plate	0.38mm 0.5mm can customized



Printing sections:

1. plate roller circumference: 300-1000mm, standard less than 400mm 2. print material: resin plate or rubber plate 3. Transmission between printing roller and anilox roller: Helical gears 4. printing chromatography: 360-degree rotation 5. adjustment method: By Manual (Automatic printing after adjust by manual, when start machine, no need register color again, the printing pressure and register all keep the same.) 6. Printing roller lifting system: pneumatic

Printing sample:

Paper Film

Our Service

Pre-Sales One-stop Service * Inquiry and consulting support * Latest industry trends * More fit printing solution * Sample testing support * View our Factory * Suggest layout support	After-Sales Service * One year warranty * Machine test video before delivery * English Manual, Electric Diagram * Training how to install the machine, * training how to use the machine * Engineers available to service machinery overseas
